Your AS/NZS 1163 Cold-Formed Structural Steel Hollow Sections manufacturer
Longma export and stock AS/NZS 1163 cold-formed steel hollow section. Specifies the requirements for the production and supply of cold-formed, electric resistance-welded, steel hollow sections used for structural purposes. It considers three strength grades(AS/NZS 1163 C250 Hollow Section; AS/NZS 1163 C350 Hollow Section; AS/NZS 1163 C450 Hollow Section), with or without impact properties, that are suitable for welding.
- Grades: C250/C250L0, C350/C350L0, C450/C450L0
- Out Diameter: 114.3-1142.2mm(4″-56″)
- Wall Thickness: 6.02-50.8mm(0.237″ – 2″)
- Length: 3-12.5 meters
0tons
Annual Output
0
Square Meters Of Plant
0+
Years Rich Experience
0+
Senior Technical Personnel
Our Certifications
Our AS/NZS 1163 Cold-Formed Structural Steel Hollow Sections Product List
Longma produce & export AS/NZS 1163 C250/C350/C450 Cold Formed Steel Hollow Sections since 2003.
AS 1163 Grade C250 Hollow Section
AS 1163 Grade C350 Hollow Section
AS 1163 Grade C450 Hollow Section
AS 1163 Grade C250 L0 Structrual Section
AS 1163 Grade C350 L0 Structrual Section
AS 1163 Grade C450 L0 Structrual Section
AS 1163 Grade C250 ERW Steel Pipe
AS 1163 Grade C350 LSAW Steel Pipe
AS 1163 Grade C450 Round Steel Pipe
Longma produce & export AS/NZS 1163 C250/C350/C450 Cold Formed Steel Hollow Sections since 2003
- Longma produce & export AS/NZS 1163 C250/C350/C450 Cold Formed Steel Hollow Sections since 2003.
- Foundin 2003, specialized in produce ERW, LSAW, DSAW steel pipes with an annual output of 300,000 tons.
- Two factories, 200,000 square meters of plant.
- Advanced production equipment imported from Germany, 16 JCO production lines.
- More than 300 employees and more than 60 technicians provide efficient production operations and technical services.
- API 5L(No. 5L-0685, Expiration date: 16th,Nov,2024), ISO9001, ISO14001, ISO18001, FPC certificates.
- Exports high quality steel pipes to more than 60 countries around the world.
AS/NZS 1163 Cold-Formed Structural Steel Hollow Sections Production Line
Annual output of 300,000 tons of LSAW steel pipes, with out diameter Φ406mm- 1626mm (16″ – 64″), wall thickness 6.0mm- 75mm (1/4″ – 3″), length 18 meters max.
X-Ray Testing
Ultrasonic Testing
Tack Welding
Plate Ultrasonic Testing
Pipe Forming
Pipe End Bevelling
Mechanical Expansion
Hydrostatic Pipe Testing
Our Advantages For AS/NZS 1163 Cold-Formed Structural Steel Hollow Sections
Complete Specifications
Out diameter up to 1422mm, and wall thickness up to 100mm, length up to 18 meters, it can cover the needs of most projects.
Good Quality
Complete quality inspection process and inspection equipments, each steel pipe has a unique code can be traced.
Fast Delivery
Our two factory areas, 16 production lines and multi -specifications of circular production. Fastest delivery time 7 days.
Quick Quotation
Dozens of professional salesmen are responsible for customers in different regions, and can provide accurate quotes within as soon as 1 hour.
Accept Small Quantity Order
Tens of thousands of tons of steel pipe inventory can meet your minimum 1 steel pipe needs.
Complete Certificate
API 5L, ISO9001, ISO14001, ISO18001, FPC, etc. While ensuring product quality, it can help you get more orders.
Technical Data For AS/NZS 1163 Cold-Formed Structural Steel Hollow Sections
| Chemical Composition, % | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Grade | C | Si | Mn | P | S | Mo | Al | Ti | Micro-alloying elements | CEV |
| C250 | 0.12 | 0.05 | 0.5 | 0.04 | 0.03 | 0.1 | 0.1 | 0.04 | 0.03 | 0.25 |
| C250L0 | 0.12 | 0.05 | 0.5 | 0.04 | 0.03 | 0.1 | 0.1 | 0.04 | 0.03 | 0.25 |
| C350 | 0.2 | 0.25 | 1.6 | 0.04 | 0.03 | 0.1 | 0.1 | / | 0.15 | 0.39 |
| C350L0 | 0.2 | 0.25 | 1.6 | 0.04 | 0.03 | 0.1 | 0.1 | / | 0.15 | 0.39 |
| C450 | 0.2 | 0.45 | 1.6 | 0.04 | 0.03 | 0.35 | 0.1 | / | 0.15 | 0.39 |
| C450L0 | 0.2 | 0.45 | 1.6 | 0.04 | 0.03 | 0.35 | 0.1 | / | 0.15 | 0.39 |
| Mechanical Properties,Min | ||||
|---|---|---|---|---|
| Steel grade | Yield strength ReH MPa | Tensile strength Rm MPa | Elongation A % | Impact energy test temperature/Individual test/Average of 3 tests/(J) |
| C250 | 250 | 320 | 22 | |
| C250L0 | 250 | 320 | 22 | 0℃/20/27 |
| C350 | 350 | 430 | 20 | |
| C350L0 | 350 | 430 | 20 | 0℃/20/27 |
| C450 | 450 | 500 | 16 | |
| C450L0 | 450 | 500 | 16 | 0℃/20/27 |
Circular Shape – Tolerances on dimensions
*External Dimensions (D): +1%, with a minimum of +0.5 mm
*Thickness (T): +10% of specified Wall Thickness
*Out-of-roundness: 2% for hollow sections having d/t≤100
*Straightness (e): 0.20% of total length
*Mass per unit length: Not less than 096 times the specified mass
Building construction, water conveying, steel structure, shipbuilding.
FAQs
Frequently Asked Questions
Here are some common questions and answers. If you still have questions, don’t hesitate to contact us.
1. What is Australian Standard AS 1163?
Specifies the technical requirements for cold-formed steel hollow sections for structural purposes, for the six grades of steel that are suitable for welding.
2. What is AS NZS 1163 Grade 350?
AS/NZS 1163 C350/C450 RHS is a range of structural and general-purpose cold formed electric resistance welded square and rectangular hollow sections. AS/NZS 1163 C350 RHS, These products are manufactured to meet the mechanical property requirements of both C350 and C450 and are suitable for welding and limited bending.
3. What are the properties of AS NZS 1163 Grade C350?
Produced by vacuum arc re-melting, C350 provides a very high strength nominally 350 ksi tensile (2415 MPa) with an above-average level of toughness. The alloy retains its tensile strength up to 450°C, and good notch impact is maintained down to minus 50°C and below.
4. What is AS NZS 1163 Grade C300 Steel?
C300 is an age hardenable (maraging) iron nickel stainless steel. C300 has exceptional strength, toughness and is resistant to crack propagation. C300 is used for tooling, transmission shafts, autosport components and light aircraft landing gear.
5. What grades are included in the AS NZS 1163 standard?
The standard AS NZS 1163 is included Grade C250, C250L0, C350, C350L0, C450, C450L0.
6. What is the difference betweenAS NZS 1163 C250 and C350 grade steel?
While grade AS NZS 1163 C250 is commonly used in most applications, there are a wide array of grades available for specific purposes. AS NZS 1163 Grade 350, for example, is stronger. Steel Grade 1045 is designed for high-heat applications such as gears or moving parts that have friction applied to them often.
